THE RAPID INSTITUTE

A different
perspective for
Lab-on-a-Disc

Meet μVID, a universal visualisation, imaging, and detection platform for modern microfluidics.

View the poster
Developed at The RAPID Institute
Dublin City University, Ireland
FIG. 01SYSTEM ARCHITECTURE
The μVID system architectureA stationary overhead reflector directs the optical path between a microfluidic disc and a co-rotating camera, mounted above the spindle assembly.OVERHEADREFLECTORALIGNMENTMECHANISMOPTICAL PATHCAMERAROIMICROFLUIDICDISCRSIMMODULESPINDLE ASSEMBLY
Drawing the architecture
0.0 / 6.6s
THE μVID SYSTEM

A new way to see
lab-on-a-disc.

μVID uses a co-rotating camera to view a microfluidic disc through a stationary overhead reflector. This keeps the disc’s features spatially fixed in the image during rotation.

  1. 01

    Imaging

    Observe microfluidic features while the disc rotates.

  2. 02

    Computation

    All computation happens on board the device, from image processing to assay analysis.

  3. 03

    Analysis

    Turn captured images into quantitative measurements for microfluidic assays.

Read the research poster

Conor M. Curley & colleagues
The RAPID Institute, Dublin City University
With Karlsruhe Institute of Technology
